?RB4P-G22DC是安川（YASKAWA）公司生產的一款繼電器模塊?，屬于時間繼電器或中間繼電器類型，采用固體繼電器工作原理。以下是其詳細參數：

一、基礎信息

• ?品牌?：YASKAWA安川
• ?型號?：RB4P-G22DC
• ?類型?：時間繼電器/中間繼電器
• ?工作原理?：固體繼電器

二、電氣參數

• ?動作信號?：速度/電壓

• ?動作時間?：延時繼電器，動作時間通常在20ms以下（不含彈跳時間）

• ?輸出形式?：無觸點式/觸點式（不同來源描述有差異）

• ?額定電壓?：可能為240V、DC110V或220V（不同來源描述有差異）

• ?額定電流?：22A（部分描述未明確）

• ?額定使用電流?：DC110V下為0.3A，AC220V下為0.5A（部分描述）

• ?接點規格?：

  • 接點構成：4a或2a2b（部分描述）
  • 額定絕緣電壓：AC250V（商用頻率：50/60Hz）
  • 額定通電電流：2A
  • 大輸入電流：AC220V下為15A
  • 接點大斷路電流：AC220V下為15A
  • 初期接觸電阻：500mΩ以下（DC6V，1A）

• ?電氣壽命?：

  • B10=100萬次（DC110V，1倍閉路、1倍斷路設定，誘導負載L/R=40ms）
  • B10=30萬次（其他條件）

• ?時間特性?：

  • 動作時間：20ms以下（不含彈跳時間）
  • 復位時間：20ms以下（不含彈跳時間）
  • 彈跳時間：3ms以下

• ?絕緣與耐壓?：

  • 絕緣電阻：100MΩ以上（DC500V兆歐）
  • 耐電壓：接點間商用頻率AC500V，1分鐘（電流峰值5mA）；輸入輸出間、接點相互間、對地面間商用頻率AC1500V，1分鐘（電流峰值5mA）

三、環境適應性

• ?使用溫度?：-40℃～+70℃
• ?保管溫度?：-40℃～+75℃
• ?耐振動特性?：IEC61373 Category 1 Class B
• ?耐沖擊特性?：IEC61373 Category 1 Class B

四、外形與安裝

• ?外形尺寸?：可能包括22mm（部分描述）
• ?安裝類型?：卡鎖（部分描述）
• ?端接樣式?：導軌（部分描述）
• ?封裝/規格?：IP56/IP55（部分描述）

RB4P-G22DC is a relay module produced by Yaskawa (YASKAWA) company, belonging to the type of time relay or intermediate relay, and using the working principle of solid-state relay. Here are its detailed parameters:
1、 Basic Information
Brand: YASKAWA Yaskawa
Model: RB4P-G22DC
Type: Time Relay/Intermediate Relay
Working principle: Solid state relay
2、 Electrical parameters
Action signal: speed/voltage
Action time: Delay relay, action time is usually below 20ms (excluding bounce time)
Output format: contactless/contact type (different source descriptions may vary)
Rated voltage: may be 240V, DC110V, or 220V (different source descriptions may vary)
Rated current: 22A (some descriptions are not clear)
Rated operating current: 0.3A at DC110V and 0.5A at AC220V (partial description)
Contact specifications:
Contact composition: 4a or 2a2b (partially described)
Rated insulation voltage: AC250V (commercial frequency: 50/60Hz)
Rated current: 2A
High input current: 15A at AC220V
Contact large open circuit current: 15A under AC220V
Initial contact resistance: below 500m Ω (DC6V, 1A)
Electrical lifespan:
B10=1 million times (DC110V, 1 times closed circuit, 1 times open circuit setting, induced load L/R=40ms)
B10=300000 times (other conditions)
Time characteristics:
Action time: less than 20ms (excluding bounce time)
Reset time: less than 20ms (excluding bounce time)
Bounce time: less than 3ms
Insulation and voltage resistance:
Insulation resistance: 100M Ω or above (DC500V megaohms)
Voltage endurance: Commercial frequency between contacts is AC500V, 1 minute (peak current of 5mA); Commercial frequency AC1500V, 1-minute (peak current 5mA) between input and output, contacts, and ground
3、 Environmental adaptability
Operating temperature: -40 ℃~+70 ℃
Storage temperature: -40 ℃~+75 ℃
Vibration resistance characteristics: IEC61373 Category 1 Class B
Impact resistance characteristics: IEC61373 Category 1 Class B
4、 Appearance and Installation
Dimensions: may include 22mm (partially described)
Installation type: card lock (partially described)
End connection style: rail (partially described)
Packaging/Specifications: IP56/IP55 (Partial Description)
