?IC695PSD040是GE Fanuc RX3i系列的一款24伏直流40瓦電源模塊

?IC695PSD040是GE Fanuc RX3i系列的一款24伏直流40瓦電源模塊

?IC695PSD040是GE Fanuc RX3i系列的一款24伏直流40瓦電源模塊

?IC695PSD040是GE Fanuc RX3i系列的一款24伏直流40瓦電源模塊

?IC695PSD040是GE Fanuc RX3i系列的一款24伏直流40瓦電源模塊?，專為工業控制應用設計，能夠?qū)⒔涣麟娀蛑绷麟娹D(zhuǎn)換為穩定的24伏直流電，為系統中的各種電子元件提供可靠的電力供應。

?主要參數詳情?

1. ?輸入電壓范圍?：

   • ?交流輸入?：85-264V AC，47-63Hz（部分資料提及，適用于交流轉直流場景）
   • ?直流輸入?：18-30V DC（啟動模式），12-30V DC（運行模式）

2. ?輸出電壓?：

   • ?標稱額定電壓?：24V DC
   • ?輔助輸出?：+5.1V DC（標準輸出），+3.3V DC（RX3i模塊常用）

3. ?功率與負載能力?：

   • ?輸入功率?：60瓦
   • ?負載能力?：40瓦（最大輸出功率）
   • ?輸出電流?：0-6A 或 0-9A（根據負載需求自動調節）

4. ?物理特性?：

   • ?外殼?：流線型藍色防護外殼，采用優質材料制造。
   • ?接線端子?：支持14 AWG至18 AWG電線，端子額定電流6A。
   • ?尺寸?：緊湊設計，適應工業環境空間限制。

5. ?保護功能?：

   • ?過電流保護?：防止短路或過載導致的硬件損壞。
   • ?輸入過電壓保護?：抑制電壓波動對模塊的影響。
   • ?浪涌電流限制?：啟動時浪涌電流4A，持續100毫秒。
   • ?溫度監控?：LED指示燈提示超溫狀態。

6. ?狀態指示?：

   • ?電源指示燈（綠色）?：模塊供電正常。
   • ?P/S故障指示燈（紅色）?：電源模塊故障或電壓不足。
   • ?超溫指示燈（琥珀色）?：模塊接近或超過工作溫度。
   • ?過載指示燈（琥珀色）?：輸出接近或超過最大功率。

7. ?環境適應性?：

   • ?工作溫度范圍?：寬范圍設計，適應惡劣工業環境。
   • ?防護等級?：高防護標準，確保穩定運行。

?功能特點?

• ?自動電壓適應?：輸入電壓波動時自動調節，保持輸出穩定。
• ?智能開關熔絲?：內置限流功能，短路時自動關斷電源。
• ?背板兼容性?：僅適用于通用背板，支持帶電熱插拔，減少停機時間。
• ?冗余模式限制?：在PACSystems RX3i系統中，不可與其他RX3i電源共用冗余模式。

?應用場景?

• ?工業自動化設備?：為PLC系統、DCS、CNC等提供穩定直流電源。
• ?控制系統?：支持GE Fanuc RX3i系列PACSystems的電力需求。
• ?需要可靠電源的場景?：如工廠生產線、機器人控制、能源管理系統等。

IC695PSD040 is a 24V DC 40W power module from GE Fanuc RX3i series, designed specifically for industrial control applications. It can convert AC or DC power into stable 24V DC power, providing reliable power supply for various electronic components in the system.
Main parameter details
Input voltage range:
Communication input: 85-264V AC, 47-63Hz (as mentioned in some materials, suitable for AC to DC conversion scenarios)
DC input: 18-30V DC (start mode), 12-30V DC (run mode)
Output voltage:
Nominal rated voltage: 24V DC
Auxiliary output:+5.1V DC (standard output),+3.3V DC (commonly used in RX3i module)
Power and load capacity:
Input power: 60 watts
Load capacity: 40 watts (maximum output power)
Output current: 0-6A or 0-9A (automatically adjusted according to load requirements)
Physical characteristics:
Shell: Streamlined blue protective shell, made of high-quality materials.
Terminal block: Supports 14 AWG to 18 AWG wires, with a rated current of 6A for the terminal.
Size: Compact design, suitable for industrial environment space limitations.
Protection function:
Overcurrent protection: prevents hardware damage caused by short circuits or overloads.
Input overvoltage protection: suppresses the impact of voltage fluctuations on the module.
Surge current limit: A surge current of 4A during startup, lasting for 100 milliseconds.
Temperature monitoring: LED indicator light indicates over temperature status.
Status indication:
Power indicator light (green): The module is powered normally.
P/S fault indicator light (red): power module fault or insufficient voltage.
Overtemperature indicator light (amber): The module is approaching or exceeding its maximum operating temperature.
Overload indicator light (amber): Output close to or exceeding maximum power.
Environmental adaptability:
Working temperature range: Designed with a wide range, suitable for harsh industrial environments.
Protection level: High protection standard to ensure stable operation.
Functional Features
Automatic voltage adaptation: Automatically adjusts when the input voltage fluctuates to maintain stable output.
Intelligent switch fuse: Built in current limiting function, automatically shuts off power in case of short circuit.
Backboard compatibility: Only applicable to universal backboards, supporting hot swapping to reduce downtime.
Redundancy mode limitation: In the PACSystems RX3i system, redundancy mode cannot be shared with other RX3i power supplies.
Application scenarios
Industrial automation equipment: provides stable DC power supply for PLC systems, DCS, CNC, etc.
Control system: Supports the power requirements of GE Fanuc RX3i series PACSystems.
Scenarios that require reliable power sources, such as factory production lines, robot control, energy management systems, etc.
