產品特點：
●封閉式機械外觀設計，符合CE 標準。將機械設計，安全原理，國際質量標準融于一體，健康環保，方便快捷。
Closed mechanical design, in accordance with CE standard. The mechanical design, safety principles, combine international quality standards, healthy environmental protection, convenient and quick.
●專門針對成卷商標或卷料開片連續自動切割而開發。采用500萬像素視覺識別系統，單刷視野范圍大，識別效果好。可根據加工需求，選擇連續自動識別切割功能和定位圖形切割功能。
Specifically for roll trademark or coil drive continuous automatic cutting and development. Using 5 million pixels visual identification system, single brush wide field of vision, good recognition effect. Can choose according to processing requirements, automatic identification of continuous cutting function and positioning graphics cutting function.
●能克服成卷商標位置偏移，送料卷料張力影響商標變形等問題，使成卷商標送料，切割和收料一氣呵成，形成完全自動化操作。
Roll label position offset can be overcome, feeding coiling tension affect deformation of trademark, make trademark roll feeding, cutting and receive the same material, form a complete automation.
適用材料及行業：
●適用于織嘜商標，繡標，印花，印標，卷標等材料
Applicable to trademarks of woven label, embroidery, printing, printed label, label etc
●適用于數碼印花，商標生產企業
Suitable for digital printing, trademarks production enterprise
主要技術參數：
|
激光類型Laser type
|
玻璃管封離Co2激光器
|
Glass tube sealing Co2 laser
|
|
激光輸出功率Thelaserpoweroutput
|
80w/110w/130w/150w
|
80w/110w/130w/150w
|
|
加工幅面Processing wide
|
300x200（mm）
|
300x200（mm）
|
|
工作平臺Work platform
|
履帶工作平臺
|
Bo caterpillar work platform
|
|
加工速度Processing speed
|
可調
|
adjustable
|
|
定位精度Positioningaccuracy
|
±0.1mm
|
±0.1mm
|
|
運動系統Motor system
|
伺服運動系統
|
servo motor system
|
|
冷卻系統The coolingsystem
|
水循環冷卻機
|
Water circulating cooling machine
|
|
供電電源Power supply
|
AC220V±5% 50/60HZ
|
AC220V±5% 50/60HZ
|
|
支持圖形格式ForMatSupport
|
AI BMP PLT DXF DST 等
|
AI BMP PLT DXF DST etc
|
|
標配The standard
|
1800萬像素CCD，微型空壓機，750W風機
|
18 million pixel CCD, mini air compressor, 750 w fan
|
|
選配optional
|
2400萬像素CCD
|
24 million pixels CCD
|
|
尺寸size
|
2600*2300*1300（長*寬*高 單位：mm）
|
2600*2300*1300（Unit of length * width * height: mm）
|
|
重量The weight of the
|
650KG
|
650KG
|
|
