分類:
|
E7018-G, SFA/AWS A5.5, E 46 6 Mn1Ni B 32 H5, EN ISO 2560-A
|
|
認(rèn)證:
|
3Y H5, ABS, 3Y H5, BV, EN 13479, CE, 3Y H5, DNV, 6Y H5, GL, 5Y42 H5, LR, UNA 272581, Seproz
|
Approvals are based on factory location. Please contact ESAB for more information.
|
Coating Type:
|
Basic
|
|
Diffusible Hydrogen:
|
< 5.0 ml/100g
|
|
Welding Current:
|
AC, DC+-
|
焊縫金屬分析
夏比V型缺口沖擊性能
|
Impact Value
|
Testing Temperature
|
|
ISO As welded
|
|
110 J
|
-40 °C
|
|
75 J
|
-60 °C
|
Typical Tensile Properties
|
Elongation
|
Tensile Strength
|
Yield Strength
|
|
ISO As welded
|
|
28 %
|
630 MPa
|
550 MPa
|
|
AWS As welded
|
|
-
|
-
|
-
|
熔敷數(shù)據(jù)
|
Fusion time per electrode at 90% I max
|
kg weld metal/kg electrodes
|
Number of electrodes/kg weld metal
|
安培
|
熔敷率
|
電壓 V
|
直徑
|
|
59 hr
|
0.65 kg
|
87
|
55-85 A
|
0.7 kg/h
|
24 V
|
2.5 x 350 mm
|
|
63 hr
|
0.63 kg
|
55
|
100-125 A
|
1.05 kg/h
|
21 V
|
3.0 x 350 mm
|
|
60 hr
|
0.57 kg
|
54
|
80-140 A
|
1.12 kg/h
|
23.8 V
|
3.2 x 350 mm
|
|
63 hr
|
0.61 kg
|
41
|
125-175 A
|
1.4 kg/h
|
21.6 V
|
3.5 x 350 mm
|
|
78 hr
|
0.63 kg
|
31
|
120-180 A
|
1.51 kg/h
|
22 V
|
4.0 x 350 mm
|
|
109 hr
|
0.608 kg
|
24
|
120-170 A
|
1.4 kg/h
|
22.2 V
|
4.0 x 450 mm
|
|
106 hr
|
0.62 kg
|
15
|
180-270 A
|
2.22 kg/h
|
24.3 V
|
5.0 x 450 mm
|
|
