| 產品參數(shù) | | 品牌 | 安普 | | 屏蔽層 | 非屏蔽雙絞線 | | 線芯材質 | 裸銅線 | | 護套材質 | PVC | | 纖芯絞合方式 | 對絞 | | 傳輸速率 | 100Kpbs | | 抗拉強度 | 16N | | 芯數(shù) | 8 | | 使用溫度 | 0-60℃ | | 儲存溫度 | -20-60℃ | | 抗壓強度 | 14N | | 適用范圍 | 弱電 | | 布線 | | 產品認證 | UL | | 加工定制 | 否 | | 可售賣地 | 全國 | | 類型 | 超五類/CAT5e | | 型號 | CS24 | | .jpg)
| Cable Component Type | Horizontal | | Cable Type | U/UTP (unshielded) | | Conductor Type, singles | Solid | | Conductors, quantity | 8 | | Jacket Color | Gray | | Pairs, quantity | 4 | | Transmission Standards | ANSI/TIA-568.2-D | CENELEC EN 50288-6-1 | ISO/IEC 11801 Class E |
Dimensions | Cable Length | 100.002 m | 328.09 ft | | Diameter Over Jacket, nominal | 5.105 mm | 0.201 in | | Conductor Gauge, singles | 24 AWG |
Electrical Specifications | Operating Voltage, maximum | 80 V | | Remote Powering | Fully complies with the recommendations set forth by IEEE 802.3bt (Type 4) for the safe delivery of power over LAN cable when installed according to ISO/IEC 14763-2, CENELEC EN 50174-1, CENELEC EN 50174-2 or TIA TSB-184-A |
Material Specifications | Conductor Material | Bare copper | | Insulation Material | Polyolefin | | Jacket Material | PVC |
Environmental Specifications | Operating Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
Packaging and Weights Regulatory Compliance/Certifications | Agency | Classification | | ROHS | Compliant | | CHINA-ROHS .jpg)
| Below maximum concentration value |
|
.jpg)
